Key technical specifications
| Item Name | Technical Parameters | Remarks |
| 1 | Output Voltage Range | 0 ～ 50kV |
| 2 | Frequency | 50Hz ～ 1000Hz |
| 3 | Voltage Control Accuracy | ±1.0% |
| 4 | Frequency Resolution | ±0.1Hz |
| 5 | Voltage Resolution | 0.01kV |
| 6 | Operating Time | Continuous operation |
Application Areas/Industries
It is primarily used for ultra-wideband withstand voltage testing. It serves to evaluate the design field strength of transformer oil and insulating paper, thereby supporting the design of high-field-strength insulation systems; it also enables the study of failure modes and residual life of transformer insulation systems and the assessment of insulation reliability, ensuring reliable operation of the transformer insulation throughout its entire lifecycle.
